Gildemeister GMX 300 linear

Control : Siemens 840D

Turning diam. : 640 mm

Turning length : 1500 mm

____________

Description

Mainspindle

Technology:Motorspindle

Speed:5.000 rpm

Torque:370 Nm

C-Axis:0,001°

Bar capacity:65 mm

Workpiececlamping:3-Jaw chuck

Schunk ROTA NCF plus 315-104

Subspindle

Technology:Motorspindle

Speed:5.000 rpm

Torque:370 Nm

C-Axis:0,001°

Bar capacity:65 mm

Workpiececlamping:3-Jaw chuck

Schunk ROTA NCF plus 315-104

Movement in Z:1.500 mm

Toolcarrier I (X/Y/Z/B)

Technology:Millingspindle

Speed:12.000 rpm

Torque:100 Nm

Taper:HSK-A63

Movement in X/Y/Z:550/220/1.585 mm

Rapid traverse in X/Y/Z:40/24/70 m/min

B-Axis:240°

Toolcarrier II (X/Z)

Technology:Turret with 12 stations

Taper:VD40

Tooldrive:4.000 rpm

10,7 kW

32 Nm

Movement in X/Z:225/1.400 mm

Rapid traverse in X/Z:24/40 m/min

Toolmagazine

Technology:Shelfmagazin with Double-gripper

Toolstations:120

Toollength (max.):200 mm

Tool-ø (max.):80 mm

Equipment/Accessory

Chipmanagement:Chip conveyor

Coolingmanagement:Internal cooling unit with Paperbeltfilter and high-pressure

Workpiecemeasurement:Touchprobe

Marposs WRP 45

Oilmistseperator:Mechanical Extraction

IFM IFMC 1100

Further Accessory:Rinsing pistol
